Test my lens and solution required

This is a discussion on Test my lens and solution required within the Digital photography forums, part of the Photography & Fine art photography category; hey all, After experiencing alot of problem on sharpness, I have decided to test my equipments. For now, I am ...

  1. #1
    Yisehaq's Avatar
    Yisehaq is offline Senior Member
    Join Date
    Jun 2008
    Location
    Ethiopia
    Posts
    977
    My Photos
    Please feel free to edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default Test my lens and solution required

    hey all,

    After experiencing alot of problem on sharpness, I have decided to test my equipments. For now, I am testing my lens.

    I used the following technique suggested by jlabel.

    lens sharpness-how to test

    Quote Originally Posted by jlabel View Post
    The best way to check technical focus is using your camera on a tripod and focusing and shooting a ruler, chose a number and shoot it if the focus is misplaced it may be a lens problem, some newer cameras have the option to configure this kind of problem, also you will be able to see if your lens is sharp enought for you, you should also use f/5.6 or f/8 for this test.
    Additional info.

    I used a tripod, mirror was locked up and all shots were taken using a cable release. The focus point was [20] on all the shots.
    No PP what so ever.

    My lens is Sigma APO 70-300mm F4-5.6 DG MACRO
    My camera is Canon 350D

    what do you think?
    Attached Images Attached Images








  2. #2
    Marko's Avatar
    Marko is offline Administrator
    Join Date
    May 2005
    Location
    Montreal, QC. Canada
    Posts
    14,120
    My Photos
    Please do NOT edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    To me the "20" does not look tack sharp.

    What format were they taken in (RAW/JPG)

    IF they were shot in RAW, did you sharpen them at anytime before you uploaded them?

    IF they were shot in JPG, did you sharpen them at anytime before you uploaded them?

    Thx - Marko
    - Please connect with me further
    Photo tours of Montreal - Private photography courses
    - Join the new Photography.ca Facebook page
    - Follow me on Twitter http://twitter.com/markokulik
    - Follow me on Google+ https://plus.google.com/u/0/111159185852360398018/posts
    - Check out the photography podcast


    "You have to milk the cow quite a lot, and get plenty of milk to get a little cheese." Henri Cartier-Bresson from The Decisive Moment.

  3. #3
    Yisehaq's Avatar
    Yisehaq is offline Senior Member
    Join Date
    Jun 2008
    Location
    Ethiopia
    Posts
    977
    My Photos
    Please feel free to edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    Thanks for your reply Marko,


    Quote Originally Posted by marko View Post
    To me the "20" does not look tack sharp.

    What format were they taken in (RAW/JPG)

    IF they were shot in RAW, did you sharpen them at anytime before you uploaded them?

    IF they were shot in JPG, did you sharpen them at anytime before you uploaded them?

    Thx - Marko
    It was shot in JPG. No post processing what so ever done on this pictures. They are just out of the camera. May be only cropped.

  4. #4
    tirediron is offline Senior Member
    Join Date
    Jul 2008
    Posts
    1,201

    Default

    The problem with this method is that the target, the [20] is not square to the film plane, so your images are suffering from a parallax error. The best way to do this would be to repeat it, using a series of vertical targets such as matchboxes in a staggered line.

  5. #5
    Marko's Avatar
    Marko is offline Administrator
    Join Date
    May 2005
    Location
    Montreal, QC. Canada
    Posts
    14,120
    My Photos
    Please do NOT edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    Although T.I. is correct, it would have been better if both camera and subject were on the same plane, I'm not convinced that's the problem.

    Do you know if your camera is sharpening the images? There should be a setting in the menu that tells you if any sharpening is going on.

    If no sharpening is going on, that may be it. In my experience (though I only shoot RAW) digital images need to be sharpened.

    any other opinions? Thx! Marko
    - Please connect with me further
    Photo tours of Montreal - Private photography courses
    - Join the new Photography.ca Facebook page
    - Follow me on Twitter http://twitter.com/markokulik
    - Follow me on Google+ https://plus.google.com/u/0/111159185852360398018/posts
    - Check out the photography podcast


    "You have to milk the cow quite a lot, and get plenty of milk to get a little cheese." Henri Cartier-Bresson from The Decisive Moment.

  6. #6
    EJC
    EJC is offline Senior Member
    Join Date
    Oct 2008
    Location
    Calgary, Alberta
    Posts
    389
    My Photos
    Please feel free to edit my photos

    Default

    Here is a more elaborate test with instructions. Focus Test

    I hope this helps

    cheers

  7. #7
    Greg_Nuspel's Avatar
    Greg_Nuspel is offline Senior Member
    Join Date
    Jan 2009
    Location
    Calgary
    Posts
    1,947
    My Photos
    Please ask before editing my photos

    Default

    Quote Originally Posted by EJC View Post
    Here is a more elaborate test with instructions. Focus Test

    I hope this helps

    cheers
    You beat me to it
    --Greg Nuspel

    I've been sucked into the void of video!!!!!!!

    Flickr

    Vimeo

  8. #8
    Yisehaq's Avatar
    Yisehaq is offline Senior Member
    Join Date
    Jun 2008
    Location
    Ethiopia
    Posts
    977
    My Photos
    Please feel free to edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    Thanks all of you.


    Quote Originally Posted by marko View Post
    Do you know if your camera is sharpening the images? There should be a setting in the menu that tells you if any sharpening is going on.
    There is a setting parameter 1 which has sharpening scale +1. These days, I only use RAW for any purpose.

    I tried to use Focus Test but couldn't get it exactly. I will give it a try once more.

  9. #9
    Marko's Avatar
    Marko is offline Administrator
    Join Date
    May 2005
    Location
    Montreal, QC. Canada
    Posts
    14,120
    My Photos
    Please do NOT edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    I don't understand Yisehaq.

    Why did you shoot these in Jpg if you ALWAYS shoot RAW?

    We need to eliminate variables 1 at a time for ease. You should test the camera/lens by shooting in RAW because that's the way you normally shoot.

    i think there's a strong chance this is a simple sharpening issue.

    I'd like to see 2 shots shot in raw and converted to JPG.
    - On a tripod with a cable release
    - both camera and subject on a flat plane

    - 1 shot you'll sharpen (in photoshop or GIMP etc.) and one shot you won't. What PP software do you use?
    - Please connect with me further
    Photo tours of Montreal - Private photography courses
    - Join the new Photography.ca Facebook page
    - Follow me on Twitter http://twitter.com/markokulik
    - Follow me on Google+ https://plus.google.com/u/0/111159185852360398018/posts
    - Check out the photography podcast


    "You have to milk the cow quite a lot, and get plenty of milk to get a little cheese." Henri Cartier-Bresson from The Decisive Moment.

  10. #10
    Yisehaq's Avatar
    Yisehaq is offline Senior Member
    Join Date
    Jun 2008
    Location
    Ethiopia
    Posts
    977
    My Photos
    Please feel free to edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    Thanks Marko

    Quote Originally Posted by marko View Post

    Why did you shoot these in Jpg if you ALWAYS shoot RAW??
    I didn't know that the file types affect the sharpeness. I shot in jpg because I want the file size to be small to upload without any PP manupilations, RAW conversion etc.

    Quote Originally Posted by marko View Post

    I'd like to see 2 shots shot in raw and converted to JPG.
    - On a tripod with a cable release
    - both camera and subject on a flat plane

    - 1 shot you'll sharpen (in photoshop or GIMP etc.) and one shot you won't. What PP software do you use?
    I use photoshop CS2

    Does both camera and subject on a flat plane mean subject and camera sensor on parallel fields?

    I will do that and upload soon.
