Pinhole help!

This is a discussion on Pinhole help! within the Show your photo (Color) - Landscape & Nature (flowers, mountains, storms etc.) forums, part of the Photography & Fine art photography category; I tried to make my DSLR into a pinhole camera today by cutting out a thin piece of cardboard, and ...

  1. #1
    Realist's Avatar
    Realist is offline Senior Member
    Join Date
    Mar 2007
    Location
    Oklahoma
    Posts
    931
    My Photos
    Please ask before editing my photos
    Critiques
    Critique my photos anywhere in the forum

    Default Pinhole help!

    I tried to make my DSLR into a pinhole camera today by cutting out a thin piece of cardboard, and poking a thumbtack through the middle. The images are extremely blurry, and I'm wondering if the hole is to big, or if something else is the issue here. Perhaps it may not work with a DSLR. Does anyone know anything about pinhole cameras? Here are some test pics.

    This one is my curtains.
    Name:  IMG_3004.JPG
Views: 205
Size:  178.4 KB

    Here is a self-portrait from about 2 feet away.

    Name:  IMG_3003.JPG
Views: 170
Size:  224.1 KB

    Last is some alcohol bottles, because the stereotypical drunk has blurry vision.

    Name:  IMG_3022.JPG
Views: 175
Size:  192.2 KB

  2. #2
    ewaizel is offline Senior Member
    Join Date
    Sep 2012
    Location
    Vancouver BC Canada
    Posts
    610
    My Photos
    Please do NOT edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    You can try Aluminum foil instead. That's in my experiment list with my DSLR.

  3. #3
    Realist's Avatar
    Realist is offline Senior Member
    Join Date
    Mar 2007
    Location
    Oklahoma
    Posts
    931
    My Photos
    Please ask before editing my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    Quote Originally Posted by ewaizel View Post
    You can try Aluminum foil instead. That's in my experiment list with my DSLR.
    Well no luck with the foil. I bet the pinhole has to move forward or backward from the sensor, not sure which way though.

  4. #4
    Barefoot's Avatar
    Barefoot is offline Senior Member
    Join Date
    Jan 2009
    Location
    Aiken, SC
    Posts
    2,359
    My Photos
    Please do NOT edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    What's the in camera aperture you're using?
    We don't see things as they are, we see them as we are. -Ana´s Nin

    http://barefoot.pixu.com/

  5. #5
    Realist's Avatar
    Realist is offline Senior Member
    Join Date
    Mar 2007
    Location
    Oklahoma
    Posts
    931
    My Photos
    Please ask before editing my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    Quote Originally Posted by Barefoot View Post
    What's the in camera aperture you're using?
    I took the lens off, and put a piece of cardboard over the opening with a pinhole in it. I've heard of pinhole cameras for 35mm film, they're supposed focus everything I believe.

  6. #6
    Doug L's Avatar
    Doug L is offline Senior Member
    Join Date
    Oct 2011
    Location
    Ottawa, Ontario
    Posts
    347
    My Photos
    Please ask before editing my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    Quote Originally Posted by Realist View Post
    ...pinhole cameras ... focus everything I believe.
    Never tried to make a pinhole camera, but as far as I figure, the huge depth-of-field is due to the set up having a hugely long focal ratio (because of the tiny aperture). So, moving the pinhole farther away from the sensor might be best. Also, if that makes the exposures become too long (multiple seconds?), a tripod will be mandatory. I wonder if the quality (raggedness or smoothness) of the hole edge affects the image? Anyway, sounds like a fun project. Keep experimenting.

  7. #7
    Andrew is offline Senior Member
    Join Date
    Jun 2009
    Location
    Victoria, BC. Canada
    Posts
    444
    My Photos
    Please ask before editing my photos

    Default

    The distance of the pin hole should only change the size of the image projected on the plain of the film or sensor. In my own DSLR the camera likes to know what lens is on it and makes adjustment in software for it. Manual lenses still work but there are a few adjustments to make. Make sure everything on the camera is in a manual mode.

  8. #8
    asnow is offline Senior Member
    Join Date
    Jul 2010
    Location
    mississauga, on
    Posts
    4,975
    My Photos
    Please feel free to edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    I have no experience with pinhole cameras but here is a link from Chris Marquardt who made his own pinhole camera. Chris has a podcast Tips From The Top Floor and I'm sure if you sent him a question on your problem he would send you his suggestion on a solution

    Blog || Chris Marquardt - Photography, Photo Workshops, Videography

    Photography Tips from the Top Floor | The free show about all things photography with Chris Marquardt

  9. #9
    Realist's Avatar
    Realist is offline Senior Member
    Join Date
    Mar 2007
    Location
    Oklahoma
    Posts
    931
    My Photos
    Please ask before editing my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    Quote Originally Posted by asnow View Post
    I have no experience with pinhole cameras but here is a link from Chris Marquardt who made his own pinhole camera. Chris has a podcast Tips From The Top Floor and I'm sure if you sent him a question on your problem he would send you his suggestion on a solution

    Blog || Chris Marquardt - Photography, Photo Workshops, Videography

    Photography Tips from the Top Floor | The free show about all things photography with Chris Marquardt
    Well I found another video off of the one you posted. Apparently they make pinhole lenses out of body caps for nikon and canon. Those ones are $50. Also went on to explain that like I mentioned earlier they do have a huge depth of field, but they have soft focus. The pinhole cameras are not tack sharp by any means. Well I've learned quite a bit, it's always good to learn something new.

  10. #10
    ewaizel is offline Senior Member
    Join Date
    Sep 2012
    Location
    Vancouver BC Canada
    Posts
    610
    My Photos
    Please do NOT edit my photos
    Critiques
    Critique my photos anywhere in the forum

    Default

    I decided to also experiment a little with this. I created pinhole viewers to watch an eclipse before. I tried to apply the same approach to the camera.

    As you can see below, I used aluminum foil and I created a really tiny pinhole. I mean, really tiny, probably 1/4 of a mm. This could be improved by pressing a needle against a hard surface with the foil in between.
    I used an extension tube which allowed me to change the distance between the sensor and the foil.





    This is the result. The diameter of the pinhole affects the image sharpness. The bigger the hole the less sharp the image will be.
    The distance between the pinhole and the sensor affects the magnification. The smaller the distance, the smaller the magnification. In other words, if you start moving the pinhole away from the sensor the magnification will increase.
    The image below was done using a distance of about 5cm.
    Almost everything was in focus, the lemon at 10cm of the pinhole and the stove 3 meters away.
    I was not getting a vignetting effect like some pinhole negative cameras do. Probably because the sensor was totally covered by the image.
    Good luck and keep playing.
